4 Data Modules and Asynchronous Data Units
Connect Data Modules
6. If you pressed ENTER/YES in the preceding step and the
CI2 LEAD = ON? prompt appears press the ENTER/YES button again to
confirm your selection.
7. When the SET CH LEAD? prompt appears, press the NEXT/NO button to
keep the default (OFF) or the ENTER/YES button
8. If you pressed ENTER/YES in the preceding step and the CH LEAD =
ON? prompt appears, press the ENTER/YES button again to confirm your
selection.
9. If the SET CH2 LEAD? prompt appears, press the NEXT/NO button to
keep the default (OFF) or the ENTER/YES button
CI2 LEAD=ON?
Push the button indicated by the arrow ( )
SET CH LEAD?
Choose a button indicated by the question mark (?)
CH LEAD=ON?
Push the button indicated by the arrow ( )
SET CH2 LEAD?
Choose a button indicated by the question mark (?)
NEXT/NO BACK ENTER/YES
DATA
make a change.
to
DATA NEXT/NO BACK ENTER/YES
?
NEXT/NO BACK ENTER/YES
DATA
make a change.
to
DATA NEXT/NO BACK ENTER/YES
?
