Music-on-Hold, Dial Dictation, or Recorded Announcement Access

Music-on-Hold, Dial Dictation, or
Recorded Announcement Access
Figure 51
announcement features when the music source is Federal Communications
Commission (FCC) registered (or equivalent).
connections when the music source is not FCC-registered (or equivalent).
NOTE:
Use the following connection instructions when the music source is not
located in the equipment room. If the music source is located in the
equipment room, do not route the connections through the information
outlet.
1
1. Music source
2. 4-pair modular cord
3. 103A or modular wall jack
4. 122A music adapter (if required) primarily
France
Figure 51. Typical Registered Equipment Connections (Auxiliary Access)
1. If the music source is registered, the system side of the MDF connects
directly to the system.
2. If the music source is not registered, the system side of the MDF connects
to a 909A/B universal coupler.
Registered Music Source
Refer to Figure 51
1. Determine feature port assignment from Feature-Related System
Parameters Form.
2. Install music source per the manufacturer's instructions.
3. Install patch cord/jumper wires at the main distribution frame.
4. Administer the switch for the new equipment.
shows the connections for music-on-hold, dial dictation, or recorded
2
to install a registered music source.
Figure 52 on page 165
4
3
5
cydfmusc RPY 090397
5. Tip (green) and ring (red)
6. Part of main distribution frame
7. A25D 25 pair cable (male-to-male) to
auxiliary trunk circuit pack
Issue 1
April 2000
shows the
6
7
