18 Multimedia Communications Products: MMCX, MMCH, ESM
Multimedia Call Handling (MMCH)
7. Set the Signaling Mode: field to isdn-pri
8. Set the Connect: field to pbx
9. Set the Interface: field to network
10. Set the Country Protocol:field to 1
11. Set the Protocol Version:field to a
12. Set the CRC?:field to y
13. The Idle Code default is 11111111.
14. The DCP/Analog Bearer Capability default is 3.1 kHz.
15. Set the MMI Cabling Board: field to xxxxx (where xxxxx is the
location of the TN787F/H/J/K MMI circuit pack recorded in step 2). This
must be the slot for port B of the Y-cable.
16. The MMI Interface: field ESM appears.
17. Enter add signaling-group next and the signaling-group form appears.
18. Change Associated Signaling: field to y.
19. Change Primary D-Channel Port: field to xxxx17 (where xxxx is the
address of the TN2207 PRI circuit pack, for example: 1B0517).
20. The Max Number of NCA TSC: default is 0.
21. The Max Number of GA TSC: default is 0.
22. Trunk Group for NCA TSC: ____ (leave blank)
23. Trunk Group for Channel Selection:____ (leave blank)
24. Logoff the terminal and then log back on the terminal to view your
changes.
Place Test Call
Place multimedia data-conference call to an endpoint with known video
capability to test the esm function.
Troubleshooting
To determine ESM link status enter the following commands from the system
administration terminal:
1. Status esm
2. Status signaling-group
3. List MMI
