DEFINITY
Release 5
8434DX Voice Terminal
Quick Reference
555-230-857
Comcode 107672982
Refer to the procedures on this card to use the
features on your 8434DX voice terminal. The features
here are listed in alphabetical order. In the spaces
provided, write the feature access codes for your
system. For more information about any of these
features, see your system manager or refer to the
DEFINITY
8434DX Voice Terminal User's Guide , 555-230-856.
USING THE SOFTKEYS
You can display any of the softkey features by pressing
and then the softkey below the feature
Menu
abbreviation. If the feature you want to use is not on
the bottom line of the screen, press
until you see the feature you wish to access.
Prev
When the feature is active, an arrow appears above
the feature. (However, if the feature requires you to dial
a telephone number or extension, such as Call
Forwarding, you will temporarily see the digits you are
dialing, rather than the arrow, above the feature
name.)
ABBREVIATED DIALING (AD)
To program/reprogram an AD button
1 Pick up handset.
NOTE: For speakerphone users, press a call
appearance button.
2 Press softkey below Prog (if shown on the display)
or Press
or Dial AD Program access code _________.
3 Press AD button to be programmed.
Enterprise Communications Server (ECS)
®
Generic 1 and Generic 3 and System 75
Program
Next
1
or

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Voice Terminal 8434DX and is the answer not in the manual?

Questions and answers

ERIKA COLBY
May 4, 2025

HOW DO YOU GET THE CALLER ID BACK ON THE SCREEN

0

Subscribe to Our Youtube Channel

Related Manuals for Lucent Technologies Voice Terminal 8434DX

Summary of Contents for Lucent Technologies Voice Terminal 8434DX

  • Page 1 ® DEFINITY Enterprise Communications Server (ECS) Release 5 8434DX Voice Terminal Quick Reference 555-230-857 Comcode 107672982 Refer to the procedures on this card to use the features on your 8434DX voice terminal. The features here are listed in alphabetical order. In the spaces provided, write the feature access codes for your system.
  • Page 2 4 Dial outside number, extension, or feature access code you want to store (up to 24 digits). NOTE: You may be able to use the softkeys to add special functions such as Pause, Mark, Wait, or Suppress into the telephone numbers programmed on the AD button.

  • Page 3: Automatic Callback

    NOTE: An Enhanced List may also be available. 2 Dial desired list item (1, 2, 3...). AUTOMATIC CALLBACK To automatically place another call to an extension that was busy or did not answer 1 During call attempt, press softkey below AutCB (if shown on the display) or Press AutoCallBk...
  • Page 4 To talk privately with a coworker after answering a redirected call 1 Press Transfer Call is put on hold. 2 Press the softkey below Cnslt (if shown on the display) or Press Consult or Dial coworker’s extension appearance 3 Discuss call, if appropriate. 4 If coworker is not available, press the call appearance button next to the fluttering light to reconnect to the call...

  • Page 5: Call Pickup

    To retrieve a parked call from any extension. 1 Dial Answer Back access code _______. 2 Dial extension where call is parked. CALL PICKUP To answer a call placed to a member of your pickup group 1 Press softkey below CPkUp (if shown on the display) or Press Call Pickup...

  • Page 6: Last Number Dialed

    NOTE: If you want to call the displayed number, press Call Display and then dial the number using the dial pad. EXIT When you are ready to leave Display or Softkey Mode and return to Normal (call-handling) Mode 1 Press Exit HOLD To put a call on hold...

  • Page 7: Priority Calling

    To cancel a Leave Word Calling message 1 Press the softkey below CnLWC (if shown on the display) or Press Cancel LWC or Dial Leave Word Calling cancel code _______. 2 Dial extension. PRIORITY CALLING To place a priority call (3-burst ring) 1 Press the softkey below PCall (if shown on the display) or Press...

  • Page 8: Send All Calls

    3 To set your selected ringing pattern: if your 8434DX has a when you hear the desired ringing pattern; if your 8434DX has a anymore. You will hear the selected ringing Ring pattern two more times, and then it will be automatically saved.
  • Page 9 To prevent the other party from hearing you 1 Press Mute Red Mute light goes on. 2 Press Mute Red Mute light goes off. To change from speakerphone to handset 1 Pick up handset and talk. To change from handset to speakerphone 1 Press Speaker 2 Hang up handset.
  • Page 10 2 Dial number where call is to be transferred. 3 Press Transfer 4 Hang up. Prepared by BCS Product Documentation Development Middletown, NJ 07748-9972 and the softkey Menu and the softkey Menu again. again. Issue 2, February 1997 Copyright © 1997 Lucent Technologies Printed in USA...
