4 Data Modules and Asynchronous Data Units
Connect Data Modules
8. When the LOCAL LOOP/ST? prompt appears on the LCD, press the
NEXT/NO button.
9. When the REMOTE LOOPBACK? prompt appears on the LCD, press the
NEXT/NO button.
10. When the RESET OPTIONS? prompt appears on the LCD, press the
ENTER/YES button.
The factory options are restored, and you return to the HOME screen.
POWER
TEST
Configuring the 7400B Data Module
The factory default settings for the7400B data module are generally satisfactory.
But if you need to change them, you use a terminal device and the AT command
language commonly used by Hayes-compatible modems (7400B data modules
LOCAL LOOP/ST?
Push the button indicated by the arrow ( )
REMOTE LOOPBACK?
Push the button indicated by the arrow ( )
RESET OPTIONS?
Push the button indicated by the arrow ( )
D D D R
T S R C T
R R I D S
0 0 — 0 0
7400A Data Module
DATA
DATA
DATA
C
T T R
S D D
0 — —
DATA
April 2000
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
HOME
NEXT/NO BACK ENTER/YES
