4 Data Modules and Asynchronous Data Units
Connect Data Modules
4. Press the NEXT/NO button until you see the yourSpeed =ON? prompt.
Then press the ENTER/YES button.
5. If the CONTINUE? prompt appears, press the ENTER/YES button.
Setting the automatic-answer feature on the 7400D
You can set up the 7400A data module to automatically answer calls or you can
have it ignore calls until an operator answers manually. Set up the data module
for automatic answering unless specifically directed to otherwise.
1. When the SET ANSWER? prompt appears, press the ENTER/YES
button.
2. When the ANS = AUTO? prompt appears, press the ENTER/YES button
for most applications.
Configuring the RS-232 interface of the 7400D
From the front panel, you can set each pin of the RS-232 cable to meet the needs
of specific applications, though in most cases, the settings below should work.
yourSpeed =ON?
Push the button indicated by the arrow ( )
CONTINUE?
Push the button indicated by the arrow ( )
SET ANSWER?
Push the button indicated by the arrow ( )
ANS = AUTO?
Push the button indicated by the arrow ( )
NEXT/NO BACK ENTER/YES
DATA
DATA NEXT/NO BACK ENTER/YES
DATA NEXT/NO BACK ENTER/YES
DATA NEXT/NO BACK ENTER/YES
