Operation mode 530, 532,
554
15 - Warning current limitation
Controller current limit. long
16 -
term Ixt
Controller current limit.
17 -
short term Ixt
18 - Controller current limit Tk
Controller current limit.
19 -
motor temp.
20 - Comparator 1
21 - Comparator 2
22 - Warning V-belt
23 - Timer 1
24 - Timer 2
25 - Warning mask
26 - Warning, application
27 - Warning mask, application
Warning gen. + warning
28 -
appl.
Warning mask gen. +
29 -
Warning mask appl.
30 - Flux forming finished
41 - Release brake
43 - External fan
50 - Synchronization Fault
1)
51 - Signal Fault
2)
56 - Phasing Done
1) 2)
57 - In Gear
58 - Position Comparator
2)
59 - Homing DONE
176
A controller or Operation Mode 573 of the intelligent current
limits limit the output current.
The overload reserve for 60 s has been used up and the output
current is being limited.
The overload reserve for 1 s has been used up and the output
current is being limited.
Max. heat sink temperature T
of Operation Mode 573 active.
Max. motor temperature reached, intelligent current limits of
Operation Mode 573 active.
The comparison according to the selected Op. Mode
Comparator 1 540 is true.
The comparison according to the selected Op. Mode
Comparator 2 543 is true.
Warning of Operation Mode 581 of V-belt Montoring.
The selected Operation Mode Timer 1 790 generates an output
signal of the function.
The selected Operation Mode Timer 2 793 generates an output
signal of the function.
Message of the configurable parameter Create Warning Mask
536.
A warning application is signaled. Display of the actual value is
effected via parameter
Message of the configurable parameter
626.
Mask
A warning or warning application is signaled.
Message of configurable parameters Create Warning Mask 536
and
Create Appl. Warning Mask
Magnetic field has been impressed.
Activation of a brake unit depending on Operation Mode 620 for
the staring behavior, Operation Mode 630 for the stopping
behavior or the configured brake control system.
The Switch-On Temperature 39 was reached.
The phase error of the index control exceeded the
1)
597.
Level
Index signal period too short during index control.
Message of phasing function. For positioning in combination with
the function of the electronic gear, the value Phasing: Offset
1125 was reached.
Synchronization of the electronic gear is reached. The slave
drive is engaged and operates at a synchronous angle with the
master.
The current actual value is in the range between
2)
1243 to
Off-Position
value of parameter
Homing was started and the reference position for a positioning
operation was set.
Operating Instructions ACU
Function
reached, intelligent current limits
K
Application Warnings
Create Appl. Warning
626.
1244 of the position comparator. The set
1245 is considered.
Hysteresis
273.
Warning
On-Position
12/16
