BONFIGLIOLI ACTIVE CUBE 201 Operating Instructions Manual page 197

Parameter
No. Description
791 Time 1 Timer 1, signal delay
792 Time 2 Timer 1, signal duration
794 Time 1 Timer 2, signal delay
795 Time 2 Timer 2, signal duration
Examples of the timer function depending on the selected operation mode and the input signal:
Parameter
Operation Mode Timer 1
Input
Time 1
Output
As soon as the positive signal edge is received at the input, time 1 is started. Once the Time 1
(signal delay) has elapsed, the output signal will be switched for Time 2 (signal duration).
In the settings for signal duration (
output signal will not be reset.
Parameter
Operation Mode Timer 1
Input
Time 1
Output
As soon as the positive signal edge is received at the input, time 1 is started. If a positive signal
edge is detected within the signal delay (Time 1), Time 1 will start again (Retrigger). Once the Time
1 (signal delay) has elapsed, the output signal will be switched for Time 2 (signal duration).
In the settings for signal duration (
output signal will not be reset.
: Time not run out completely
: Time run out completely
12/16
Min.
0.00 s/m/h
0.00 s/m/h
0.00 s/m/h
0.00 s/m/h
Normal, positive edge
790 or
Operation Mode Timer 2
Time 2
Time 2 Timer 1
Retrigger, positive edge
790 or
Operation Mode Timer 2
Time 1 Time 2
Time 2 Timer 1
Operating Instructions ACU
Setting
Max.
650.00 s/m/h
650.00 s/m/h
650.00 s/m/h
650.00 s/m/h
793 = 1
Factory setting (Time 2 = 0)
792 = 0 and
Time 2 Timer 2
793= 2
Facory setting (Time 2 = 0)
792 = 0 and
Time 2 Timer 2
Factory setting
0.00 s/m/h
0.00 s/m/h
0.00 s/m/h
0.00 s/m/h
795 = 0), the
795 = 0), the
197
