BONFIGLIOLI ACTIVE CUBE 201 Operating Instructions Manual page 184

Create Warning Mask 536
Controller
34 -
Voltage Pre-Control
35 - Controller I abs
Controller
36 -
Torque Limitation
Controller
37 -
Torque Control
38 - Ramp stop
Contr. intel. curr. lim. LT-
39 -
Ixt
Contr. intel. curr. lim. ST-
40 -
Ixt
41 - Contr. intel. curr. lim. Tc
Contr. intel. curr. lim. motor
42 -
temp.
Controller
43 -
Frequ. Limitation
101 to 143
The current warning mask can be read via parameter
Operation Modes of parameter
537. The code is calculated by hexadecimal addition of the individual operation modes and the
corresponding abbreviation
184
The Dyn. Voltage Pre-Control 605 accelerates the control
characteristics.
The output current is limited
The output power or the torque are limited by the speed
controller
Switch-over of field-oriented control between speed and torque-
controlled control method.
The Operation mode 620 selected in starting behavior limits the
output current.
Overload limit of the long-term Ixt (60s) reached, intelligent
current limits active
Overload limit of the short-term Ixt (1s) reached, intelligent
current limits active.
Max. heat sink temperature T
intelligent current limits active.
Max. motor temperature T
intelligent current limits active.
The reference frequency has reached the Maximum Frequency
419. The frequency limitation is active.
Removal or deactivation of the operation mode within the
warning mask
536 are encoded in the
Create Warning Mask
Operating Instructions ACU
Function
reached, Operation Mode 573 for
K
reached, Operation Mode 573 for
PTC
Actual Warning Mask
Actual Warning Mask
537. The above
12/16
