302 Energy, negative
The actual values can be read out and monitored in the VAL menu branch of the
operating unit. Parameter
of the actual value parameters to be selected.
Parameter
Reset Memory
unit enables purposeful resetting of the individual mean and peak values. The peak value and the
mean value with the values stored in the period are overwritten with the parameter value zero.
Reset Memory 237
0 - No Reset
Peak Value Long Term
1 -
Ixt
Peak Value Short Term
2 -
Ixt
3 - Peak value Vdc
4 - Average value Vdc
5 - Peak value Tc
6 - Average Tc
7 - Peak value Ti
8 - Average Ti
9 - Peak Value Irms
10 - Average Value Irms
11 - Peak value Pactive pos.
12 - Peak value Pactive neg.
13 - Average Pactive
16 - Energy, positive
17 - Energy, negative
100 - All peak values
101 - All average values
102 - All values
20.4

Actual values of the system

The calculation of the actual figures of the system is based on the parameterized system data.
Specific to the application, the parameters are calculated from the factors, electrical variables and
the controls. The correct display of the actual figures is a function of the data of the system to be
parameterized.
20.4.1

Actual value system

The drive can be monitored via actual value
The
Actual Frequency
and can be read out via parameter
389 =
Actual Value System
No. Description
242 Actual Value System
12/16
The calculated energy from the motor in generator operation.
Control Level
237 which is to be selected in the PARA menu branch of the operating
Values of actual value memory remain unchanged.
Reset Peak Value Long Term Ixt 231
Reset Peak Value Short Term Ixt 232
Reset Peak Value Vdc 287.
Delete Average Value Vdc 288.
Reset Peak Value Heat Sink Temp. 289.
Delete Average Value Heat Sink Temp. 290.
Reset Peak Value Inside Temperature 291.
Delete Average Value Inside Temperature 292.
Reset Peak Value Irms 293.
Delete Average Value Irms 294.
Reset Peak Value Active Power pos. 295.
Reset Peak Value Active Power neg. 296.
Delete Average Value Active Power 297.
Reset parameter Energy, positive 301.
Reset parameter Energy, negative 302.
Reset all saved peak values.
Delete average values and saved values.
Delete the entire actual value memory.
Actual Value System
241 to be monitored is multiplied by the
Actual Value System
Actual Value System
Actual Value System
Calculated frequency of drive.
Operating Instructions ACU
28 in PARA menu branch defines the selection
Function
242.
Factor Actual Value System
242, i.e.
Actual Frequency
242.
Function
389
241 x
Factor
