16.2

Multifunction Output MFO1

Multifunction output MFO1 can either be configured as a digital, analog or a repetition frequency
output. Depending on the selected
various functions of the software is possible. The operation modes not used are deactivated
internally.
Operation Mode 550
0 - off
1 - Digital
2 - Analog
3 - Repetition frequency
16.2.1

Analog Output MFO1A

By default, the multifunction output MFO1 is configured for the output of a pulse width modulated
output signal with a maximum voltage of DC 24V.
The selected configuration determines which actual values can be selected for parameter
553 of Multifunction output 1.
Operation
Analog Operation 553
0 - off
1 - Abs. Fs
Abs. Fs betw.
2 -
fmin/fmax
3 - Abs. Speed Sensor 1
7 - Abs. actual frequency
20 - Abs. Iactive
21 - Abs. Isd
22 - Abs. Isq
30 - Abs. Pactive
31 - Abs. M
32 - Abs. inside temperature
Abs. Heat Sink
33 -
Temperature
Abs. value analog input
40 -
MFI1A
50 - Abs. I
51 - DC-Link Voltage
52 - U
53 - Volume Flow
12/16
Operation Mode
Output has the logic signal LOW
Digital output, 0 ... 24 V
Analog output, 0 ... 24 V
Repetition frequency output, 0 ... 24 V, f
Analog operation MFO1 is switched off.
Abs. value of the Stator Frequency
0,00 Hz ...
Maximum Frequency
Abs. value of the Stator Frequency
Minimum Frequency 418 ...
Abs. value of speed sensor signal 1,
0,00 Hz ...
Maximum Frequency
Abs. value of act. frequency,
0,00 Hz ...
Maximum Frequency
Abs. value of current effective current I
0.0 A ... Inverter rated current.
Abs. value of flux-forming current component,
0.0 A ... Inverter rated current.
Abs. value of torque-forming current component,
0.0 A ... Inverter rated current.
Abs. value of current active power P
0.0 kW ...
Rated Mech. Power
Abs. value of calculated torque M,
0.0 Nm ... rated torque.
Abs. value of measured inside temperature,
0 °C ... 100 °C
Abs. value of measured heat sink temperature,
0 °C ... 100 °C
Abs. signal value at analog input MFI1A,
0.0 V ... 10.0 V.
Abs. current value of measured output currents,
0.0 A ... Inverter rated current.
DC-Link Voltage U ,
d
0.0 V ... 1000.0 V.
Output voltage U,
0.0 V ... 1000.0 V.
Abs. value of calculated volume flow
3
0.0 m /h ...
Nominal Volumetric Flow
Operating Instructions ACU
550 for the multifunction output, a link to
Function
= 150 kHz
max
Function
419.
Maximum Frequency
419.
419.
,
WIRK
,
WIRK
376.
397.
Analog
419.
173
