Sto Status; Actual Values Of Machine - BONFIGLIOLI ACTIVE CUBE 201 Operating Instructions Manual

20.1.1

STO Status

Parameter
STO Status
The statuses of the inputs are shown in bit-encoded form.
Bit Value
0 1 STOA input missing.
1 2 STOB input missing.
2 4 Switch off STOA input.
3 8 Switch off STOB input.
4 16 Timeout STOA.
5 32 Timeout STOB.
6 64 Diagnosis error.
7 128 FI error (fault).
With correct wiring and correct function, only the 2 states "0" (= STO enabled) and "3" (= STO
disabled) are typically shown (decimal representation) in parameter
The signal states at digital inputs STOA and STOB can be linked to functions of the frequency
inverter.
292 - STOA
284 - STOA inverted
293 - STOB
285 - STOB inverted
Refer to Application manual "Safe Torque Off STO".
20.2

Actual values of machine

The frequency inverter controls the behavior of the machine in the various operating points. As a
function of the configuration selected and the expansion cards installed, control variables and further
actual value parameters of the machine can be displayed.
No. Description
210 Stator frequency
211 R.m.s Current
212 Output Voltage
213 Active Power
214 Active Current
215 Isd
216 Isq
217 Encoder 1 Frequency
218 Encoder 1 Speed
221 Slip Frequency
224 Torque
225 Rotor Flux
12/16
277 can be used for extended diagnosis of the two inputs STOA and STOB.
Signal state at digital input STOA
Inverted signal state at digital input STOA
Signal state at digital input STOB
Inverted signal state at digital input STOB
Actual values of machine
The output voltage (motor voltage) of the frequency inverter.
Calculated effective output current (motor current) of the frequency
inverter.
Calculated effective value of linked output voltage (motor voltage) of
frequency inverter.
Active power calculated from the voltage, the current and the control
variables.
Active current calculated from the rated motor parameters, the
control variables and the current.
Current component of the field-oriented control forming the
magnetic flux.
Torque-forming current component of field-oriented control.
Calculated from the data on speed sensor 1, the No. of Pole Pairs
373 and the speed sensor signal
Calculation from Encoder 1 Frequency
Difference from the synchronous frequency calculated from the rated
motor parameters, the control variables and the current.
Torque at the current output frequency calculated from the voltage,
the current and the control variables.
Current magnetic flux relative to the rated motor parameters.
Operating Instructions ACU
Meaning
STO Status
Function
277.
253
