BONFIGLIOLI ACTIVE CUBE 201 Operating Instructions Manual page 248

f
Master drive
Reference
48
Frequency
0
f
Slave drive
Reference
48
Frequency
0
Acceleration
Time
Handshake
In the case of the master drive, the superimposed traverse frequency is linearly opposite to the limit
438 and will then reverse its direction. When the direction is reversed, a
Traverse Amplitude
proportional jump is effected. Via a handshake signal, the master drive informs the slave drive that
the traverse output has changed its direction. The traverse function of the slave drive has the same
gradient as the traverse function of the master drive, but an opposite sign. When the slave drive
reaches the limit
Traverse Amplitude
frequency is maintained until switch-over is effected. If the handshake signal is received before the
frequency limit is reached, the direction is reversed immediately.
Parameter
No. Description
436 Startup time
437 Shut-down time
438 Traverse amplitude
439 Proportional jump
Reference Frequency
Handshake Traverse Function
Signal "14 – Output Wobble" is added to the reference frequency value.
248
439
Proportional Step
Deceleration
437
Time
436
438 before switch-over of the handshake signal, the
Min.
0.01 s
0.01 s
0.01 %
0.01 %
Input signals Traverse function
Operation Mode
48
Acceleration Time
49
Deceleration Time
Traverse Amplitude
Proportional Step
Operating Instructions ACU
438
Traverse Amplitude
t
t
t
Setting
Max. Factory setting
320.00 s
320.00 s
50.00 %
50.00 %
Output signals
435
14 - Sweep Output
436
15 - Sweep Handshake
437
(from Master drive)
438
439
5 s
5 s
10 %
0.01%
