1

General Information about the Documentation

1.1

Instruction Manuals

For better clarity, the documentation is structured according to the customer-specific requirements
made on the frequency inverter.
Quick start guide
The Quick Start Guide describes the basic steps required for mechanical and electrical installation of
the frequency inverter. The guided commissioning supports you in the selection of necessary
parameters and the configuration of the frequency inverter by the software.
Operating instructions
The Operating Instructions describe all functions of the frequency inverter. The parameters required
for adapting the frequency inverter to specific applications and the numerous additional functions are
described in detail.
Application manual
The application manual supplements the documentation for purposeful installation and commissioning
of the frequency inverter. Information on various subjects connected with the use of the frequency
inverter is described specific to the application.
If you need a copy of the documentation or additional information, contact your
local representative of BONFIGLIOLI.
The following instructions are available for the
ACTIVE CUBE
Instructions
ACTIVE CUBE
Quick Start Guide
Manuals
Communication interfaces
Manuals
Extension modules
Safe Torque Off (STO) manual
Operating Instructions
Cooling Supplemental
PLC application manual
12/16
ACTIVE CUBE
Operating Function of frequency inverter.
Installation and commissioning Supplied with the device.
CM-CAN: CANopen manual
CM-PDP-V1: Profibus DP-V1 manual
CM-232/CM-485: VABus manual (serial protocol)
CM-232/CM-485 Modbus: Modus ASCII and RTU manual
CM-VABus/TCP: Ethernet Module CM-VABus/TCP
CM-ModbusTCP: Ethernet Module CM-Modbus/TCP
CM-EtherCAT
CM-ProfiNet: Ethernet Module CM-ProfiNet
CM-EtherNet-I/P: Ethernet Module CM-EtherNet-I/P
EM-ABS-01: Absolute encoder module
EM-ENC-01: Speed sensor (encoder) module
EM-ENC-02: Speed sensor (encoder) module
EM-ENC-03: Speed sensor (encoder) module
EM-ENC-04: Speed sensor (encoder) module
EM-ENC-05: Speed sensor (encoder) module
EM-IO-01: Extension module for digital inputs/outputs
EM-IO-02: Extension module for digital inputs/outputs
EM-IO-03: Extension module for digital inputs/outputs
EM-IO-04: Extension module for digital inputs/outputs
EM-RES-01: Resolver module
EM-RES-02: Resolver module
EM-RES-03: Resolver module
EM-SYS: System Bus module
Safety function STO
Liquid Properties specific to liquid cooled frequency inverters
Logic linking of digital signals. Functions for analog signals such
as comparisons and mathematical functions. Graphical support
for programming with function blocks.
Operating Instructions ACU
series:
®
: Ethernet Module CM-EtherCAT
®
(i.V.)
11
