SETUP Select 796
14 - Complete Setup, DS4
Plaus.-Check Machine
20 -
Data, DS0
Plaus.-Check Machine
21 -
Data, DS1
Plaus.-Check Machine
22 -
Data, DS2
Plaus.-Check Machine
23 -
Data, DS3
Plaus.-Check Machine
24 -
Data, DS4
Calculation and Para-
30 -
Ident., DS0
31 - Calc. and Para-Ident., DS1
32 - Calc. and Para-Ident., DS2
Calc. and Para-Ident.,
33 -
DS3
Calc. and Para-Ident.,
34 -
DS4
Para-Ident., Machine Data
40 -
only, DS0
Para-Ident., Machine Data
41 -
only, DS1
Para-Ident., Machine Data
42 -
only, DS2
Para-Ident., Machine Data
43 -
only, DS3
Para-Ident., Machine Data
44 -
only, DS4
110 Complete Setup w/o Para-
- Ident., DS0
111 Complete Setup w/o Para-
- Ident., DS1
112 Complete Setup w/o Para-
- Ident., DS2
113 Complete Setup w/o Para-
- Ident., DS3
114 Complete Setup w/o Para-
- Ident., DS4
In the "Extended motor data" settings, the current controller settings are changed,
too.
The individual steps of the auto set-up routine can be monitored and checked via parameter
797. The setup routine via the communication interface continuously updates the status
Status
parameter which can be read out via the interface.
12/16
The parameter values of the auto set-up are stored in data set 4.
The auto set-up routine checks the rated motor parameters in the
four data sets.
The rated motor parameters in data set 1 are checked for
plausibility.
The rated motor parameters in data set 2 are checked for
plausibility.
The rated motor parameters in data set 3 are checked for
plausibility.
The rated motor parameters in data set 4 are checked for
plausibility.
The auto set-up routine determines extended motor data via the
parameter identification feature, calculates dependent parameters
and stores the parameter values in all of the four data sets
identically.
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 1
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 2
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 3
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 4
Extended motor data are measured and saved identically in all
data sets.
Extended motor data are measured and saved data set 1.
Extended motor data are measured and saved data set 2.
Extended motor data are measured and saved data set 3.
Extended motor data are measured and saved data set 4.
The auto set-up routine is performed in data set 0 and the
parameter values are stored in all of the four data sets identically.
Extended motor data are not measured.
The parameter values of the auto set-up are stored in data set 1.
Extended motor data are not measured.
The parameter values of the auto set-up are stored in data set 2.
Extended motor data are not measured.
The parameter values of the auto set-up are stored in data set 3.
Extended motor data are not measured.
The parameter values of the auto set-up are stored in data set 4.
Extended motor data are not measured.
