15.5

Reference percentage channel

The reference percentage channel combines various signal sources for definition of the reference
figures. The percentage scaling facilitates integration into the application, taking various process
parameters into account.
The
Reference Percentage Source
reference value sources depending on the hardware installed.
Reference Percentage Source
476
Abs. value analog value
1 -
MFI1A
2 - Abs. value EM-S1INA
Abs. value MFI1 + EM-
4 -
1)
S1INA
Abs. value fixed percentage
10 -
value (FP)
11 - Abs. value MFI1A + FP
12 - Abs. value EM-S1INA + FP
Abs. value MFI1 + EM-
14 -
1)
S1INA + FP
20 - Abs. value Motorpoti (MP)
21 - Abs. value MFI1A + MP
22 - Abs. value EM-S1INA + MP
Abs. value MFI1 + EM-
24 -
S1INA + FP
Abs. value
32 -
Rep. Freq./PWM Inp. (F3)
33 - Abs. value MFI1A + F3
Abs. value MFI1A + FP +
90 -
MP + F3 (+ EM-S1INA)
Abs. value Obj. 0x6071
95 -
Target Torque
Abs. value Profibus OUT-
96 -
PZD3
Abs. value FT outp.
99 -
percentage 1
101 to 199
1)
The reference value source is only available if an optional extension module with analog input is connected.
For information, refer to the extension module operating instructions.
156
476 determines the additive assignment of the available
Multifunction input 1 in analog Operation Mode 452 is the
reference value source.
1)
Analog input of EM-S1INA is the reference value source.
Combination of operation modes 1 and 2.
The percentage according to Fixed Percent Change-Over 1 1 75,
Fixed Percent Change-Over 2 76 and the current data set
Combination of operation modes 1 and 10.
1)
Combination of operation modes 2 and 10.
Combination of operation modes 1.2 and 10.
Reference value source: Function Percent Motorpoti Up 72 and
Percent Motorpoti Down 73
Combination of operation modes 1 and 20.
1)
Combination of operation modes 2 and 20.
Combination of operation modes 1.2 and 20.
The frequency signal on the digital input according to Operation
Mode 496 for the PWM/repetition frequency input.
Combination of operation modes 1 and 32.
Combination of the operation modes 1, 10, 20, 32
1)
(+ analog input of an extension module)
Reference value source: CANopen Object 0x6071.
Reference value source: Profibus OUT-PZD3.
Reference value source: Output of function table FT-Output
Percentage 1.
Operation modes with signs (+/-).
Operating Instructions ACU
Function
1)
