10 Inverter data

The series ACU frequency inverters are suited for a wide range of applications. The modular
hardware and software structure enables customer-specific adaptation. The available hardware
functionality of the frequency inverter is displayed in the control unit and the optional control
software VPlus. The software parameters can be adjusted to meet the requirements of the specific
application.
10.1

Serial Number

0:
Serial Number
Rating plate:
10.2

Optional Modules

Modular extension of the hardware is possible via the plug-in slots. The
detected by the frequency inverter and the corresponding designations are displayed on the control
unit and in the optional control software VPlus after initialization. For the parameters required for the
extension module, refer to the corresponding operating instructions.
10.3

Inverter Software Version

The firmware stored in the frequency inverter defines the available parameters and functions of the
software. The software version is indicated in parameter
to the version, the 6-digit software key is printed on the rating plate of the frequency inverter.
Inverter Software Version
Rating plate :
15
Copyright
10.4

Set Password

As a protection against unauthorized access, parameter
anyone who wants to change parameters must enter this password this password before. A change
of parameter is only possible if the password in entered correctly. If parameter
set to zero, no password is required for access to the parameters. The previous password is deleted.
Parameter
No. Description
27 Set Password
10.5

Control Level

The 28 defines the scope of the functions to be parameterized. The operating
Control Level
instructions describe the parameters on the third control level. These parameters should only be set
by qualified users.
Parameter
No. Description
28 Control Level
10.6

User Name

The 29 can be entered via the optional control software VPlus. ???
User Name
12/16
603409000 ; 06053980 (part no.; serial no.)
Type: ACU 401 – 09 ; Serial No.: 06053980
CM-232 ; EM-IO-01
12 : 5.4.0
Version: 5.4.0 ; Software: 15 000 190
(C) 2013 BONFIGLIOLI VECTRON
Min.
0
Min.
1
32 alphanumeric characters
Operating Instructions ACU
Optional Modules
Inverter Software Version
27 can be set such that
Set Password
Setting
Max. Factory setting
999
Setting
Max. Factory setting
3
1
12. In addition
27 is
Set Password
0
1
115
