8.5

Reference frequency and percentage value channel

The various functions for the statement of the reference figures are connected in the
various configurations by the reference frequency or percentage value channel. The
Reference Frequency Source
mine the additive connection of the available reference sources as a function of the
installed hardware.
Operation mode
Abs.
2 -
analog value EM-S1INA
Abs. value
4 -
MFI1A + EM-S1INA
Abs. value
14 - MFI1A + EM-S1INA +
FP
Abs. value
24 -
MFI1A + EM-S1INA + MP
102 to 124
Alongside the operation modes listed, those stated in the operating instructions of the
frequency inverter in the chapter "Frequency reference channel", and in the chapter
"Percentage reference channel" also apply.
8.6

Actual value display

The actual value of rotary encoder 2 can be read out via the parameters
Frequency
The analog input signal on analog input EM-S1INA is displayed via actual value para-
meter
Analog Input EM
114
475 and the
(or FF)
219 and
Encoder 2 Speed
- 253.
S1INA
EM-ABS-01 for ACU
Reference Percentage Source
Function
Reference source is the analog input EM-S1INA.
Reference sources are the multifunctional input
MFI1A and the analog input EM-S1INA.
Reference sources are the multifunctional input
MFI1A, analog input EM-S1INA and fixed percentage
(or the fixed frequency FF).
FP
Reference sources are the multifunctional input
MFI1A, analog input EM-S1INA and the motor po-
tentiometer function MP.
Operation modes with signs (+/-).
220.
476 deter-
Encoder 2
03/12
