Table 2-7: Input/Output port specifications (cont.)
Characteristic
Keyboard and Mouse ports
External audio ports
Table 2-8: Data storage specifications
Characteristic
Nonvolatile memory retention time,
typical
Real-time clock
Hard disk drive
Table 2-9: Power source specifications
Characteristic
Source voltage
Source frequency
Fuse rating
Table 2-10: Environmental specifications
Characteristic
Temperature
Humidity
Altitude
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Description
PS-2 compatible, instrument must be powered down to make connection
External audio jacks for microphone input and line output
Description
No time limit for front-panel settings, saved waveforms, setups, and calibration constants
A programmable clock providing time in years, months, days, hours, minutes, and seconds
The 2.5-inch SATA hard disk drive capacity is ≥160 GB. Waveforms and setups are stored
on the hard disk.
Description
100 V to 240 V ±10%
(85 to 264 V) 45 Hz to 66 Hz
(100 V to 132 V) 360 Hz to 440 Hz
T6.3AH, 250 Vac
The fuse cannot be replaced by the user.
Description
Operating: +5 °C to +50 °C (32 °F to +122 °F)
Nonoperating: -20 °C to +60 °C (-4 °F to +140 °F)
Operating:
8% to 90% relative humidity with a maximum wet bulb temperature of 29 °C at or below
+50 °C (upper limit derates to 20.6% relative humidity at +50 °C). Non-condensing.
Nonoperating:
5% to 98% relative humidity with a maximum wet bulb temperature of 40 °C at or below
+60 °C (upper limit derates to 29.8% relative humidity at +60 °C). Non-condensing.
Operating: 3,000 m (9,843 ft)
Nonoperating: 9,144 m (30,000 ft)
Specifications (MSO/DPO5000 Series)
2–17
