Tektronix MSO70000 Series Technical Reference page 56

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-2: Horizontal and acquisition system specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000
Series models (cont.)
Characteristic
MSO70804,
DSA/DPO70804B,
MSO70604,
DSA/DPO70604B at
25 GS/s, 6 GHz, BWE
on
MSO70804,
DSA/DPO70804B,
MSO70604,
DSA/DPO70604B,
MSO70404,
DSA/DPO70404B at
25 GS/s, 4 GHz, BWE
on
Delta Time Measurement
Accuracy, < 4 GHz models
1–40
Description
1.445 ps rms, 14.45 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.295 ps rms, 12.95 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.329 ps rms, 13.29 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
1.674 ps rms, 16.74 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.437 ps rms, 14.37 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.478 ps rms, 14.78 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
For signals having amplitude greater than 5 divisions, reference level = 50%, filter set to
sin(x)/x, acquired at 10 mV/div or greater. The displayed risetime/sample interval must be
greater than 1.4 but less than 4. Extra error will occur for two channel measurements due to
channel to channel skew. Peak specification is based on statistical accumulation of 1000
waveforms.
Single shot, sample or HiRes, full bandwidth
Average Mode, ≥100 averages, full
bandwidth selected.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
(0.06/sample rate + 2.5 ppm x | reading |)
RMS
± (0.30/(sample rate) + (2.5 ppm x | reading
|)) peak
± (2.5 ppm x | reading | + 4 ps)
