Tektronix MSO70000 Series Technical Reference page 229

Analog Bandwidth
Performance checks
Bandwidth
at
Channel Impedance Vertical scale
All Models
Channel 3 50 Ω
MSO5204, DPO5204, MSO5104, DPO5104 Only
Channel 3 1 MΩ
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Horizontal
scale
1 mV/div 5 ns/div
(175 MHz)
2 mV/div 2.5 ns/div
(350 MHz)
5 mV/div 1 ns/div
(Full BW)
10 mV/div 1 ns/div
(Full BW)
50 mV/div 1 ns/div
(Full BW)
100 mV/div 1 ns/div
(Full BW)
1 V/div 1 ns/div
(Full BW)
1 mV/div 5 ns/div
(175 MHz)
2 mV/div 2.5 ns/div
(350 MHz)
5 mV/div 1 ns/div
(Full BW)
10 mV/div 1 ns/div
(Full BW)
50 mV/div 1 ns/div
(Full BW)
100 mV/div 1 ns/div
(Full BW)
1 V/div 1 ns/div
(Full BW)
Performance Verification (MSO/DPO5000 Series)
V V
in-pp bw-pp
Test result
Limit Gain = V /V
bw-pp in-pp
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
4–15
