Tektronix MSO70000 Series Technical Reference page 39

Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
MSO72004C,
MSO71604C,
MSO71254C,
DSA72004C,
DSA71604C,
DSA71254C,
DPO72004C,
DPO71604C,
DPO71254C
where applicable
Gain setting
10 mV
15 mV
20 mV
30 mV
40 mV
50 mV
60 mV
70 mV
80 mV
90 mV
100 mV
200 mV
250 mV
300 mV
400 mV
450 mV
500 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
12.5 GHz 12 GHz 11 GHz
0.55 mV 0.53 mV 0.51 mV
0.72 mV 0.71 mV 0.68 mV
0.82 mV 0.81 mV 0.78 mV
1.24 mV 1.20 mV 1.16 mV
1.55 mV 1.49 mV 1.43 mV
1.80 mV 1.78 mV 1.72 mV
2.23 mV 2.18 mV 2.12 mV
2.67 mV 2.58 mV 2.51 mV
3.10 mV 2.98 mV 2.90 mV
3.35 mV 3.27 mV 3.14 mV
4.09 mV 4.05 mV 3.94 mV
7.76 mV 7.47 mV 7.16 mV
9.37 mV 9.03 mV 8.68 mV
10.98 mV 10.58 mV 10.19 mV
15.16 mV 14.79 mV 14.29 mV
16.88 mV 16.47 mV 15.93 mV
18.60 mV 18.15 mV 17.56 mV
10 GHz 9 GHz 8 GHz
0.49 mV 0.46 mV 0.45 mV
0.65 mV 0.63 mV 0.60 mV
0.75 mV 0.71 mV 0.67 mV
1.10 mV 1.03 mV 0.99 mV
1.39 mV 1.33 mV 1.27 mV
1.65 mV 1.57 mV 1.48 mV
1.99 mV 1.89 mV 1.79 mV
2.34 mV 2.21 mV 2.11 mV
2.78 mV 2.61 mV 2.49 mV
3.02 mV 2.86 mV 2.74 mV
3.73 mV 3.55 mV 3.36 mV
6.93 mV 6.55 mV 6.33 mV
8.35 mV 7.92 mV 7.63 mV
9.76 mV 9.30 mV 8.93 mV
13.60 mV 13.01 mV 12.40 mV
15.12 mV 14.50 mV 13.80 mV
16.65 mV 15.98 mV 15.20 mV
7 GHz 6 GHz
0.43 mV 0.40 mV
0.57 mV 0.54 mV
0.63 mV 0.60 mV
0.95 mV 0.89 mV
1.18 mV 1.10 mV
1.41 mV 1.31 mV
1.71 mV 1.60 mV
2.01 mV 1.88 mV
2.37 mV 2.25 mV
2.61 mV 2.45 mV
3.18 mV 2.99 mV
5.94 mV 5.51 mV
7.20 mV 6.68 mV
8.46 mV 7.84 mV
11.81 mV 11.07 mV
13.17 mV 12.34 mV
14.53 mV 13.61 mV
1–23
