Table 2-4: Digital acquisition specifications, MSO5000 Series
Characteristic
Threshold voltage range
Digital channel timing resolution
Logic threshold accuracy
Minimum detectable pulse width
Table 2-5: P6616 Digital Probe specifications
Characteristic
Number of channels
Input resistance, Typical
Input capacitance, Typical
Minimum input signal swing
Maximum input signal swing
Maximum Input Toggle Rate
Absolute maximum input voltage
Channel-to-channel skew
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Description
-40 V to +40 V
2 ns main memory, 60.6 ps for MagniVu memory
±(100 mV + 3% of threshold setting after calibration)
Requires valid SPC. (See page 4-26, Self Test.)
1 ns
Using MagniVu memory. Requires the use of 342-1140-00 ground clip per channel.
Description
16 digital inputs
100 kΩ to ground
3.0 pF
Measured at the podlet input. Requires the use of 342-1140-00 ground clip per channel
400 mV
p-p
Requires the use of 342-1140-00 ground clip per channel
30 V for f ≤ 200 MHz (centered around the DC threshold voltage) at the P6616
p-p in
probe tip.
10 V for f >200 MHz (centered around the DC threshold voltage) at the P6616
p-p in
probe tip.
Failure to meet this input signal requirement will compromise the AC performance of the
digital channel. It might also damage the input circuitry. See the Absolute maximum
input voltage specification.
500 MHz
Maximum frequency sine wave input that can accurately be reproduced as a logic
square wave.
Requires the use of a 342-1140-00 ground clip on each channel.
This is the maximum frequency at the minimum swing amplitude. Higher toggle rates
can be achieved with higher amplitudes.
±42 V peak at the P6616 input (not at the instrument input)
Probe input voltages beyond this limit could permanently damage the instrument and
the P6616 probe.
200 ps
Digital channel to digital channel only.
This is the propagation path skew and ignores skew contributions due to threshold
inaccuracies (see Threshold accuracy) and sample binning (see Digital channel timing
resolution). Factory calibration/deskew is required to achieve this number.
Specifications (MSO/DPO5000 Series)
2–15
