Table 3-3: Test Record - Tektronix MSO70000 Series Technical Reference

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)

Table 3-3: Test record

Instrument Serial Number:
Temperature:
Date of Calibration:
Instrument performance test
DC voltage measurement accuracy (averaged), ≥ 4 GHz models
Ch1 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
Ch1 10 mV Vert scale setting,
+5 Div position setting, -0.45 V offset
Ch1 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
Ch1 20 mV Vert scale setting,
+5 Div position setting, -0.4 V offset
Ch1 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
Ch1 50 mV Vert scale setting,
+5 Div position setting, -0.25 V offset
Ch1 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
Ch1 100 mV Vert scale setting,
+5 Div position setting, -2.0 V offset
Ch1 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
Ch1 200 mV Vert scale setting,
+5 Div position setting, -1.25 V offset
Ch1 500 mV Vert scale setting,
-5 Div position setting, 0 V offset
Ch1 500 mV Vert scale setting,
+5 Div position setting, -0 V offset
Ch2 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
Ch2 10 mV Vert scale setting,
+5 Div position setting, -0.45 V offset
Ch2 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
Ch2 20 mV Vert scale setting,
+5 Div position setting, -0.4 V offset
Ch2 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
Ch2 50 mV Vert scale setting,
+5 Div position setting, -0.25 V offset
Ch2 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Certificate Number:
RH %:
Technician:
Minimum Incoming
__________
+ 524.75 mV
__________
- 535.25 mV
__________
+ 552.75 mV
__________
- 567.25 mV
__________
+ 636.75 mV
__________
- 663.25 mV
__________
+ 2.764 V
__________
- 2.836 V
__________
+ 2.697 V
__________
- 2.803 V
__________
+ 3.394 V
__________
- 3.606 V
__________
+ 524.75 mV
__________
- 535.25 mV
__________
+ 552.75 mV
__________
- 567.25 mV
__________
+ 636.75 mV
__________
- 663.25 mV
__________
+ 2.764 V
Outgoing Maximum
__________
+ 535.25 mV
__________
- 524.75 mV
__________
+ 567.25 mV
__________
- 552.75 mV
__________
+ 663.25 mV
__________
- 636.75 mV
__________
+ 2.836 V
__________
- 2.764 V
__________
+ 2.803 V
__________
- 2.697 V
__________
+ 3.606 V
__________
- 3.394 V
__________
+ 535.25 mV
__________
- 524.75 mV
__________
+ 567.25 mV
__________
- 552.75 mV
__________
+ 663.25 mV
__________
- 636.75 mV
__________
+ 2.836 V
3–23
