Tektronix MSO70000 Series Technical Reference page 133

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test
Time base system
Long term sample rate, delay time, and internal
reference accuracy
10 MHz, < 4 GHz models
10 MHz, ≥ 4 GHz models
External reference
10 MHz
Delta time measurement, < 4 GHz models
DPO7054 only:
Delta time measurement
≥ 4 GHz models
MSO72004C and DPO72004C, BWE off
10 mV, rms
10 mV, pk-pk
50 mV, rms
50 mV, pk-pk
100 mV, rms
100 mV, pk-pk
MSO71604C and DPO71604C, BWE off
10 mV, rms
10 mV, pk-pk
50 mV, rms
50 mV, pk-pk
100 mV, rms
100 mV, pk-pk
MSO71254C and DPO71254C, BWE off
10 mV, rms
10 mV, pk-pk
50 mV, rms
50 mV, pk-pk
100 mV, rms
100 mV, pk-pk
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Minimum Incoming
__________
9999.965 kHz
__________
9999.975 kHz
Pass/Fail __________
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
__________
N/A
Outgoing Maximum
__________
10000.035 kHz
__________
10000.025 kHz
__________ Pass/Fail
__________
6.0 ps
__________
12.0 ps
__________
1.280 ps
__________
12.80 ps
__________
1.172 ps
__________
11.72 ps
__________
1.186 ps
__________
11.86 ps
__________
1.280 ps
__________
12.80 ps
__________
1.172 ps
__________
11.72 ps
__________
1.186 ps
__________
11.86 ps
__________
1.304 ps
__________
13.04 ps
__________
1.201 ps
__________
12.01 ps
__________
1.205 ps
__________
12.05 ps
3–37
