Tektronix MSO70000 Series Technical Reference page 236

Performance Verification (MSO/DPO5000 Series)
Delta Time Measurement Accuracy
Channel 4
MSO/DPO = 4 ns/Div, Source freq = 240 MHz
MSO/DPO V/Div
5 mV
100 mV
500 mV
1 V
MSO/DPO = 40 ns/Div, Source freq = 24 MHz
1 mV
5 mV
100 mV
500 mV
1 V
MSO/DPO = 400 ns/Div, Source freq = 2.4 MHz
1 mV
5 mV
100 mV
500 mV
1 V
MSO/DPO = 4 μs/Div, Source freq = 240 kHz
1 mV
5 mV
100 mV
500 mV
1 V
MSO/DPO = 40 μs/Div, Source freq = 24 kHz
1 mV
5 mV
100 mV
500 mV
1 V
MSO/DPO = 400 μs/Div, Source freq = 2.4 kHz
1 mV
5 mV
100 mV
500 mV
1 V
4–22
Source V
pp
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Test result High limit
120 ps
118 ps
117 ps
122 ps
708 ps
322 ps
236 ps
233 ps
417 ps
6.99 ns
3.01 ns
2.07 ns
2.03 ns
4.02 ns
69.9 ns
30.1 ns
20.7 ns
20.3 ns
40.2 ns
699 ns
301 ns
207 ns
203 ns
402 ns
6.99μs
3.01μs
2.07 μs
2.03 μs
4.02 μs
