Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models
Characteristic
Trigger jitter, DC coupled, A edge,
random holdoff, typical
≥ 4 GHz models
< 4 GHz models
Edge trigger sensitivity, DC
coupled, typical
≥ 4 GHz models
< 4 GHz models
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Description
100 fs using enhanced trigger placement. 1 ps rms for low frequency, fast rise time signal, A
edge, time holdoff = 30 μs
1.5 ps rms for low frequency, fast rise time signal
(DPO7104 and DPO7054: 3 ps total trigger jitter.)
All sources, positive or negative edge, for vertical scale settings ≥10 mV/div and ≤1 V/div
Trigger Source
A Event trigger
B Event trigger
Auxiliary input
Trigger Source
Main and Delayed trigger
Auxiliary input
Video trigger, Ch1 - Ch4
Sensitivity
≤ 4%FS from DC to 50 MHz
≤ 10%FS at 4 GHz
≤ 15%FS at 6 GHz
≤ 20%FS at 8 GHz
≤ 50%FS at 11 GHz
20%FS from DC to 20 GHz (typical, enhanced trigger on, auto
mode only for frequencies above 8 GHz)
≤ 4%FS from DC to 50 MHz
≤ 10%FS at 4 GHz
≤ 15%FS at 6 GHz
≤ 50%FS at 9 GHz
20%FS from DC to 20 GHz (typical, enhanced trigger on, auto
mode only for frequencies above 6 GHz)
250 mV from DC to 50 MHz, increasing to 350 mV at 1 GHz
Sensitivity
≤ 0.7 div from DC to 50 MHz
≤ 1.2 div at 2.5 GHz
≤ 2.5 div at 3.5 GHz with BWE on
1 MΩ: 250 mV from DC to 50 MHz, increasing to 350 mV at
250 MHz
50 Ω: 150 mV from DC to 50 MHz, increasing to 200 mV at
1.8 GHz
0.6 to 2.5 divisions of video sync tip
1–41
