Specifications (MSO/DPO5000 Series)
Table 2-1: Analog channel input and vertical specification (cont.)
Characteristic Description
Upper frequency 250 MHz, ±20%
limit, 250 MHz
bandwidth
limited, typical
Upper frequency 20 MHz, ±20%
limit, 20 MHz
bandwidth
limited, typical
Calculated rise Calculated Rise Time at 350/BW (MHz). The formula is calculated by measuring -3 dB bandwidth of the
time, typical oscilloscope. The formula accounts for the rise time contribution of the oscilloscope independent of the rise
time of the signal source.
Instrument
MSO5204,
DPO5204
Instrument
MSO5104, DPO5104
MSO5054, DPO5054
MSO5034, DPO5034
Instrument
MSO5204, DPO5204
MSO5104, DPO5104
MSO5054, DPO5054
MSO5034, DPO5034
Instrument
MSO5204, DPO5204
MSO5104, DPO5104
MSO5054, DPO5054
MSO5034, DPO5034
2–6
50 Ω 50 Ω
10 mV/div to 5 mV/div to
1 V/div 9.98 mV/div
175 ps 233 ps
50 Ω
5 mV/div to
1 V/div
350 ps
700 ps
1 ns
TPP1000 probe
50 mV/div to
100 mV/div
350 ps
350 ps
700 ps
I ns
TPP0500 probe
50 mV/div to
10 V/div
700 ps
700 ps
700 ps
1 ns
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
50 Ω 50 Ω
2 mV/div to 1 mV/div to
4.99 mV/div 1.99 mV/div
1 ns 2 ns
50 Ω 50 Ω
2 mV/div to 1 mV/div to
4.99 mV/div 1.99 mV/div
1 ns 2 ns
1 ns 2 ns
1 ns 2 ns
TP1000 probe TPP1000 probe
20 mV/div to 10 mV/div to
49.8 mV/div 19.9 mV/div
1 ns 2 ns
1 ns 2 ns
1 ns 2 ns
1 ns 2 ns
TPP0500 probe TPP0500 probe
20 mV/div to 10 mV/div to
49.8 mV/div 19.9 mV/div
1 ns 2 ns
1 ns 2 ns
1 ns 2 ns
1 ns 2 ns
