Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
3–112
NOTE. As the input frequency is lowered, adjust the Horizontal SCALE to
maintain about 3 to 5 eyes across the display.
e. Verify that lock is acquired. (See Figure 3-37 on page 3-113.)
f. Repeat substeps b through d for each input frequency and Baud rate listed
in the table. (See Table 3-15 on page 3-112.).
g. If all tests pass, enter passed in the test record.
3. Disconnect the hookup: Disconnect the equipment from the instrument.

Table 3-15: Clock recovery input frequencies and baud rates

Input frequency
≥ 4 GHz models
1.5625 GHz
781.25 MHz
742.19 MHz
600 MHz
575.00 MHz
546.25 MHz
390.63 MHz
388.13 MHz
< 4 GHz models
625 MHz
321.5 MHz
296.87 MHz
168.75 MHz
300 MHz
156.25 MHz
78.12 MHz
74.21 MHz
31.25 MHz
15.62 MHz
7.81 MHz
3.9 MHz
1.95 MHz
976.56 kHz
488.28 kHz
380.98 kHz
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Recovered clock baud rate
3125 Mbaud
3125 Mbaud
2968.8 Mbaud
2400 Mbaud
2300 Mbaud
2185 Mbaud
1.5625 Gbaud
1.5525 Gbaud
1.25 Gbaud
1.25 Gbaud
1.187 Gbaud
675 Mbaud
1200 Mbaud
625 Mbaud
312.5 Mbaud
296.48 Mbaud
125 Mbaud
62.5 Mbaud
31.25 Mbaud
15.65 Mbaud
7.81 Mbaud
3.9 Mbaud
1.95 Mbaud
1.52 Mbaud
