Table 3-7: Analog Bandwidth, < 3.5 Ghz Models - Tektronix MSO70000 Series Technical Reference

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-7: Analog bandwidth, < 3.5 GHz models
Reference
Vertical scale amplitude
5 mV 30 mV
10 mV 60 mV
20 mV 120 mV
50 mV 300 mV
100 mV 600 mV
200 mV 1.2 V
500 mV 3 V 1
1 V 5 V 1
1
If your generator cannot output the required amplitude, determine its maximum output at the Test frequency, and use this for the reference amplitude. The -3 dB
limit can be calculated as: 0.707 × reference amplitude.
3–62
Horizontal
scale DPO7254
1 ns 2.0 GHz
1 ns 2.501 GHz
1 ns 2.501 GHz
1 ns 2.501 GHz
1 ns 2.501 GHz
1 ns 2.501 GHz
1 ns 2.501 GHz
1 ns 2.501 GHz
c. Set the vertical scale:
For the channel you are testing, set the vertical Scale to the next setting in
the table, starting with the 100 mV setting. (See Table 3-7.)
d. Set the triggering coupling: From the button bar, touch Trigger, then
select Coupling DC.
e. Display the test signal: Do the following subparts to first display the
reference signal and then the test signal.
From the button bar touch Measure; then select the Time tab.
Touch the Freq button to measure the frequency of the current channel.
Select the Ampl tab. Touch the Amplitude button.
Touch the Statistics button, then touch the Mean button.
Touch the X (Close) button.
Set the generator output so the Chx Amplitude mean readout equals
the reference amplitude in the table. This corresponds to the vertical
scale set in substep c. (See Table 3-7.)
Record the reading on the power meter.
Set the trigger as follows:
Press the front-panel Push-Set 50% as necessary to trigger a stable
display. At full bandwidth, you may also want to make small, manual
adjustments to the trigger level. You can use the Trigger Level knob to
do this.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Test frequency
DPO7104 DPO7054
1 GHz 500 MHz
1 GHz 500 MHz
1 GHz 500 MHz
1 GHz 500 MHz
1 GHz 500 MHz
1 GHz 500 MHz
1 GHz 500 MHz
1 GHz 500 MHz
-3 dB
≥21.2 mV
≥42.4 mV
≥84.8 mV
≥212 mV
≥424 mV
≥848 mV
≥2.12 V 1
≥3.535 V 1
