Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-7: Data storage specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models
Characteristic
Hard disk
Table 1-8: Power source specification, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models
Characteristic
Power consumption
≥ 4 GHz models
< 4 GHz models
Source voltage and frequency
≥ 4 GHz models
< 4 GHz models
Value probe interface (VPI),
< 4 GHz models
1–56
Description
<1200 VA
550 Watts maximum
100 to 240 V , 50 Hz to 60 Hz, 115 V ± 10%, 400 Hz
RMS
CAT II
100 V to 240 V ± 10%, 47 Hz to 63 Hz
RMS
115 V ± 10%, 400 Hz
Probe interface allows installing, powering, compensating and controlling a wide range of
probes offering a variety of features.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Description
The 2.5-inch SATA hard disk drive capacity is ≥160 GB.
Waveforms and setups are stored on the hard disk.
