Table 2-6: Display specifications
Characteristic
Display type
Display resolution
Luminance, Typical
Waveform display color scale
Table 2-7: Input/Output port specifications
Characteristic
Ethernet interface
GPIB interface
Video signal output
USB interface
Probe compensator output voltage
and frequency, typical
Auxiliary output (AUX OUT)
Trigger Out or
Reference Clock Out
External Reference nominal input
frequency
External Reference input frequency
variation tolerance
External Reference input sensitivity
External Reference input maximum
input signal
External Reference input impedance
2–16
Description
Display area: 210.4 mm (8.28 in) (H) x 157.8 mm (6.21 in) (V), 264 mm (10.4 in) diagonal,
6-bit RGB full color, XGA (1024 x 768) TFT liquid crystal display (LCD).
1024 X 768 XGA display resolution
400 cd/m
2
The TFT display can support up to 262,144 colors. A subset of these colors are used for the
oscilloscope display, all of which are fixed colors and not changeable by the user.
Description
Standard on all models: 10/100/1000 Mbps
Available as an optional accessory that connects to the USB Device and USB Host ports
with the TEK-USB-488 GPIB to USB Adapter
The control interface is incorporated into the instrument user interface.
A 15 pin D-sub, VGA-type connector, supporting a minimum resolution range of 640X480
to 1280X1024.
1 USB device connector (2.0 Full Speed), on the instrument rear panel.
6 USB host connectors (2.0 HS), two on the instrument front and four on the rear.
Output voltage
Frequency
You can set the Auxiliary output to Trigger Out or Reference Clock Out.
Reference Clock Out: Outputs the 10 MHz oscilloscope reference clock.
Trigger Out: A HIGH to LOW transition indicates that the trigger occurred.
Trigger output logic levels
Characteristic
Vout (HI)
Vout (LO)
10 MHz
You must select either the internal reference (default) or 10 MHz external.
9.9 MHz to 10.1 MHz
You must run SPC whenever the external reference is more than 0.2% (2000 ppm) different
than the nominal reference frequency or reference at which SPC was last run. (See
page 4-26, Self Test.) The time base changes in correspondence to the fluctuations in the
external reference.
Vin 1.5V for input frequencies between 9.9 MHz and 10.1 MHz
p-p
7 V
p-p
Rin = 1.5 kΩ ±20% in parallel with 15 pF ±5 pF at 10 MHz
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
0 V to 2.5 V ±1% behind 1 kΩ ±2%
1 kHz ±25%
Limits
≥2.5 V open circuit
≥1.0 V into a 50 Ω load to ground
≤0.7 V into a load of ≤4 mA
≤0.25 V into a 50 Ω load to ground
