Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
Internal probe power,
< 4 GHz models
Probe power per probe
< 4 GHz models
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
50 W maximum
Voltage
Maximum Amperage
5 V
50 mA
12 V
2 A
Voltage Tolerance
± 5%
±10%
1–33
