Performance Verification (MSO/DPO5000 Series)
Auxiliary (Trigger) Output
Performance checks
Trigger Output
High 1 MΩ
Low 1 MΩ
Trigger Output
High 50 Ω
Low 50 Ω
4–24
Low limit
≥ 2.5 V
–
≥ 1.0 V
–
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Test result
High limit
–
≤ 0.7 V
–
≤ 0.25 V
