Table 2-2: Horizontal and acquisition system specifications
Characteristic
Sample rate
Record length
Analog channels
Option
Standard
Option 2RL
Option 5RL
Option 10RL
Record Length
Digital channels
Seconds/Division range
Maximum update rate
Aperture Uncertainty
Long-term sample rate and
delay time accuracy
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Description
Instrument
MSO5204, DPO5204,
MSO5104, DPO5104
MSO5054, DPO5054,
MSO5034, DPO5034
Number of 2 GHz
Channels
3 or 4 12.5 M
1 or 2 25 M
3 or 4 25 M
1 or 2 50 M
3 or 4 50 M
1 or 2 125 M
3 or 4 125 M
1 or 2 250 M
The record length ranges for a standard instrument are the same as for the analog channel
specification table (above).
The record length ranges for an instrument with an option are the same as for the analog
channel specifications, up to 40M.
Record length
1 K 10 K
200 ps – 40 s 200 ps – 400 s
Maximum triggered acquisition rate: >250,000 wfm/s
≤(3 ps + 0.1 ppm × record duration)
±5 ppm over any ≥1 ms time interval
Specifications (MSO/DPO5000 Series)
Maximum sample rate
10 GS/s
5 GS/s
5 GS/s
1 GHz 500 MHz
12.5 M 12.5 M
25 M 12.5 M
25 M 25 M
50 M 25 M
50 M 50 M
125 M 50 M
125 M 125 M
250 M 125 M
>10 K
200 ps – 1.00 ks
, for records having ≤1 minute duration
RMS
Number of
channels
1 or 2
3 or 4
1 – 4
350 MHz
12.5 M
12.5 M
25 M
25 M
50 M
50 M
125 M
125 M
2–9
