Tektronix MSO70000 Series Technical Reference page 60

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Width and glitch trigger, minimum
timing requirements,
<4 GHz models
Width type
Logic qualified width type
Glitch type
Logic qualified glitch type
Runt trigger sensitivity, typical
≥4 GHz models
<4 GHz models
Runt trigger, minimum timing
requirements,
≥4 GHz models
Runt type
Logic qualified runt type
Time qualified runt type
Time and logic qualified runt
type
Runt trigger, minimum timing
requirements,
< 4 GHz models
Runt type
Time qualified runt type
Logic qualified runt type
Time and logic qualified runt
type
Pattern and state trigger sensitivity,
DC coupled, typical
≥ 4 GHz models
Logic and state trigger sensitivity,
DC coupled, typical
<4 GHz models
1–44
For vertical scale settings 10 mV/div and 1 V/div
Minimum pulse
width
225 ps
190 ps
170 ps
100 ps
15% x FS from DC to 1 GHz, not violating the minimum timing requirements for each type (for
vertical settings from 10 mV/div to 1 V/div at the input connector)
1.0 division (at input connector)
A runt event occurs at the end of the runt whether or not the runt was time qualified. Logic
qualified runt triggers require that the logic condition be true during the entire duration of the
runt plus some minimum amount of time after the runt event occurred.
Minimum pulse
time
200 ps
200 ps
476 ps
520 ps
A runt event occurs at the end of the runt whether or not the runt was time qualified. Logic
qualified runt triggers require that the logic condition be true during the entire duration of the
runt plus some minimum amount of time after the runt event occurred.
Minimum pulse
time
225 ps
360 ps
Runt width +
150 ps
Runt width +
330 ps
15% x FS from DC to 1 GHz, not violating the minimum timing requirements for each type (for
vertical settings from 10 mV/div to 1 V/div at input connector)
1.0 division from DC to 1 GHz (for vertical settings from 10 mV/div to 1 V/div at input connector)
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Minimum rearm Setup time
time
250 ps N.A.
250 ps 40 ps
250 ps N.A.
250 ps 40 ps
Minimum rearm Setup time
time
300 ps N.A.
300 ps 300 ps
510 ps N.A.
360 ps 160 ps
Minimum rearm Setup time
time
250 ps N.A.
450 ps N.A.
250 ps 160 ps
250 ps 160 ps
Hold time
N.A.
175 ps
N.A.
60 ps
Hold time
N.A.
300 ps
N.A.
105 ps
Hold time
N.A
N.A.
-16 ps
175 ps
