DC Gain Accuracy
Performance
checks Bandwidth
Channel 1 DC 20 MHz
Gain Accuracy,
0 V offset, 0 V
vertical position,
50 Ω
20 MHz
Channel 1 DC
Gain Accuracy,
0 V offset, 0 V
vertical position,
1 MΩ
250 MHz
FULL
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Vertical scale Low limit
1 mV/div -2.0%
2 mV/div -1.5%
5 mV/div -1.5%
10 mV/div -1.5%
20 mV/div -1.5%
50 mV/div -1.5%
100 mV/div -1.5%
200 mV/div -1.5%
500 mV/div -1.5%
1 V/div -1.5%
1 mV/div -2.0%
2 mV/div -1.5%
5 mV/div -1.5%
10 mV/div -1.5%
20 mV/div -1.5%
50 mV/div -1.5%
63.5 mV/div -3.0%
100 mV/div -1.5%
200 mV/div -1.5%
500 mV/div -1.5%
1 V/div -1.5%
20 mV/div -1.5%
20 mV/div -1.5%
Performance Verification (MSO/DPO5000 Series)
Test result High limit
2.0%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
2.0%
1.5%
1.5%
1.5%
1.5%
1.5%
3.0%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
4–7
