Table 1-5: Digital acquisition specifications (MSO70000/C Series)
Characteristic
Minimum signal amplitude
Minimum detectable pulse width
(mainframe and logic probe), typical
Number of probe channels
Number of digital acquisition channels
Digital channel resolution
Logic threshold range
with P6780 probe
with P6717 probe
Logic threshold resolution
Logic threshold accuracy (with probe
attached), typical
Single acquisition displayed timing
uncertainty between digital channels
with P6780 probe, typical
Without deskew
After deskew
Number of digital channels available
for analog acquisition
iCapture bandwidth with general
purpose probe, typical
iCapture bandwidth with solder-in
differential probe, typical
iCapture rise time with solder-in
differential probe, typical
Position range of analog iCapture
channels
iCapture DC analog accuracy
(mainframe and probe)
Gain ranges of analog channels with
probe
Digital channel comparison values
Word Recognizer trigger functions
Combinational trigger
Edge qualified combinational
trigger
Trigger toggle rate, typical
Single channel trigger jitter,
typical
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Description
300 mV p-p; logic threshold centered in dynamic range of signal;
f ≤1.5 GHz for P6780
f ≤350 MHz for P6717
<400 ps
17
16
1 bit, either a 0 or a 1
-2 V to +5 V
-2 V to +4.5 V
-1.5 V to +4.0 V
5 mV
≤3% of threshold setting ±75 mV
160 ps
80 ps
4. Any of the 16 acquisition channels + clock qualifier channel can be displayed in place
of any analog channel on the instrument
>300 MHz
>2.5 GHz
≤200 ps
±5 divisions
±(5% of reading +0.2 division)
250 mV/div, 375 mV/div, 750 mV/div,
1.25 V/div, 1.88 V/div, 3.75 V/div
0, 1, or don't care
AND, NAND, OR, NOR
AND, NAND, OR, NOR qualified on the rising or falling edge, or either edge of CQ, the
qualifying channel
≥1.5 GHz
5 ps rms for A event edge trigger using low frequency, fast rise time signal
1–51
