Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
3. Record the reference level: Note the reading on the level meter.
4. Set the generator to the new frequency and reference level:
Change the sine wave generator to the desired new frequency.
Input the correction factor and/or the new frequency into the level meter.
Adjust the sine wave generator amplitude until the level meter again reads
the value noted in step 3. The signal amplitude is now correctly set for
the new frequency.
Equipment required
Sine wave generator (Item 9)
Level meter and power sensor (Item 10)
Two male N to female BNC adapters (Item
14)
Two precision coaxial cables (Item 4)
One or two SMA male-to-female BNC
adapters (Item 19)
1. Install the test hookup: Connect the equipment as shown in the figure below
(start with the sine wave generator connected to the instrument). (See
Figure 3-39.)
2. Set the Generator:
Set the sine wave generator to a reference frequency of 10 MHz.
Adjust the sine wave generator amplitude to the required number of
divisions as measured by the instrument.
Prerequisites
(See page 3-18, Prerequisites.)
3–115
