Tektronix MSO70000 Series Technical Reference page 24

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
Characteristic
Analog bandwidth, with P7313
active probe,
≥ 4 GHz models
Analog bandwidth, 50 Ω DC
coupled,
<4 GHz models
Instrument
DPO7354
DPO7254
DPO7104
DPO7054
Analog bandwidth, 1 MΩ DC
coupled,
< 4 GHz models
1–8
Description
MSO/DSA/DPO72004C,
MSO/DSA/DPO71604C
MSO/DSA/DPO71254C
MSO70804, DSA/DPO70804B
MSO70604, DSA/DPO70604B
MSO70404, DSA/DPO70404B
Full bandwidth, operating ambient of ≤ 30 °C (86 °F), derated by 1% for each °C above
30 °C (86 °F)
Note: The DPO7354 is guaranteed 3.5 GHz bandwidth with BWE On and can be verified with a
4-division sine wave. Typical bandwidth when measured with an 8-division sine wave is 3 GHz.
SCALE range
10 mV/div to 1 V/div
5 mV/div to 9.99 mV/div
2 mV/div to 4.99 mV/div
1 mV/div to 1.99 mV/div
10 mV/div to 1 V/div
5 mV/div to 9.99 mV/div
2 mV/div to 4.99 mV/div
1 mV/div to 1.99 mV/div
5 mV/div to 1 V/div
2 mV/div to 4.99 mV/div
1 mV/div to 1.99 mV/div
5 mV/div to 1 V/div
2 mV/div to 4.99 mV/div
1 mV/div to 1.99 mV/div
Full bandwidth, operating ambient temperature of ≤ 30 °C (86 °F), derated by 1% for each °C
above 30 °C (86 °F)
SCALE range
5 mV/div to 10 V/div
2 mV/div to 4.98 mV/div
1 mV/div to 1.99 mV/div
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
DC >12.5 GHz, typical
DC >11 GHz, typical
DC >8 GHz, typical
DC >6 GHz, typical
DC >4 GHz, typical
Bandwidth
DC to 3.5 GHz, BWE on
DC to 2.5 GHz, BWE off
DC to 2.0 GHz
DC to 500 MHz, typical
DC to 200 MHz, typical
DC to 2.5 GHz
DC to 2.0 GHz
DC to 500 MHz, typical
DC to 200 MHz, typical
DC to 1.0 GHz
DC to 500 MHz, typical
DC to 200 MHz, typical
DC to 500 MHz
DC to 400 MHz, typical
DC to 200 MHz, typical
Bandwidth
DC to 500 MHz, typical
DC to 350 MHz, typical
DC to 175 MHz, typical
