Table 1-9: Mechanical Specifications, All Mso70000/C, Dsa/Dpo70000B/C, And Dpo7000 Series - Tektronix MSO70000 Series Technical Reference

Table 1-9: Mechanical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models
Characteristic
Weight
< 4 GHz models Benchtop
configuration
Rackmount kit
≥ 4 GHz non-MSO models,
Benchtop configuration
MSO70000C Series,
Benchtop configuration
Rackmount kit, ≥4 GHz
models
Dimensions
< 4 GHz models
Benchtop configuration
< 4 GHz models
Rackmount configuration
≥ 4 GHz models
Benchtop configuration
≥ 4 GHz models
Rackmount configuration
Cooling
Required clearances
Construction material
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Description
14.0 kg (31 lbs) instrument only
21.8 kg (48 lbs) when packaged for domestic shipment
0.9 kg (2 lbs)
2.2 kg (5 lbs) kit packaged for domestic shipment
23 kg (50.6 lbs) oscilloscope only
37 kg (81.4 lbs) packaged for domestic shipment
25.0 kg (55 lbs) instrument only
39 kg (86 lbs) when packaged for domestic shipment
2.04 kg (4.5 lbs) rackmount kit
3.4 kg (7.5 lbs) kit packaged for domestic shipment
With front cover and feet
295.4 mm (11.6 in) height
468.6 mm (18.4 in) width
318 mm (12.5 in) depth
311.15 mm (12.25 in) height
482.6 mm (19.0 in) width
520.7 mm (20.5 in) depth
With front cover
278 mm (10.95 in) height
330 mm (13 in) with feet extended
451 mm (17.75 in) width
442 mm (17.4 in) depth
With rack handles
267 mm (10.5 in) height
502 mm (19.75 in) width
489 mm (19.4 in) depth
Fan-forced air circulation with no air filter
Top
Bottom
Left side
Right side
Rear
Chassis parts are constructed of aluminum alloy, front panel is constructed of plastic laminate,
circuit boards are constructed of glass laminate
Without front cover and feet
278 mm (10.95 in) height
450.8 mm (17.75 in) width
308.6 mm (12.15 in) depth
Without front cover
277 mm (10.9 in) height
330 mm (13 in) with feet extended
451 mm (17.75 in) width
432 mm (17.02 in) depth
Without rack handles
267 mm (10.5 in) height
482 mm (19 in) width
442 mm (17.4 in) depth
0 mm (0 in)
6.35 mm (0.25 in) minimum or 0 mm (0 in)
when standing on feet, flip stands down
76 mm (3 in)
76 mm (3 in) ≥4 GHz models
0 mm (0 in) ≤ 4 GHz models
0 mm (0 in) on rear feet
1–57
