Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-10: Environmental specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models
Characteristic
Temperature, < 4 GHz models
operating
Nonoperating
Temperature, ≥ 4 GHz models
operating
Nonoperating
Humidity, < 4 GHz models
operating
Nonoperating
Humidity, ≥ 4 GHz models
Humidity, operating
Nonoperating
Altitude
< 4 GHz models: operating
Nonoperating
≥ 4 GHz models: operating
Nonoperating
1–58
Description
+5 °C to +45 °C (41 °F to +113 °F), with noncondensing conditions
-40 °C to +71 °C (-40 °F to +160 °F), with 15 °C/hour maximum gradient, without disk media
installed in disk drives
+5 °C to +45 °C (41 °F to +113 °F), with 11 °C per hour maximum gradient, noncondensing,
derated 1 °C per 300 meters (984.25 feet) above 1500 meters (4921.25 feet) altitude
-20 °C to +60 °C (-4 °F to +140 °F), with 20 °C/hour maximum gradient, without disk media
installed in disk drives
8% to 80% relative humidity with a maximum wet-bulb temperature of +29 ºC (84 °F) at or
below +45 ºC (113 °F), noncondensing
Upper limit derated to 30% relative humidity at +45 ºC (+113 °F)
5% to 90% relative humidity with a maximum wet-bulb temperature of +29 ºC (84 °F) at or
below +60 ºC (140 ºF), noncondensing
Upper limit derated to 20% relative humidity at +60 ºC (+140 °F)
8% to 80% relative humidity at up to +32 °C (+90 °F)
5% to 45% relative humidity above +32 °C (+90 °F) up to +45 °C (+113 °F), noncondensing,
and is limited by a maximum wet-bulb temperature of +29.4 °C (+85 °F) (derates relative
humidity to 32% at +45 °C (+113 °F)
5% to 95% relative humidity at up to +30 °C (+86 °F),
5% to 45% relative humidity above +30 °C (+86 °F), up to +60 °C (+140 °F), noncondensing,
and is limited by a maximum wet-bulb temperature of +29.4 °C (+85 °F) (derates relative
humidity to 11% at +60 °C (+140 °F))
Up to 3,000 meters (9,843 feet)
Up to 12,192 meters (40,000 feet)
Up to 3,000 meters (9,843 feet), derate maximum operating temperature by 1 °C per
300 meters (984.25 feet) above 1500 meters (4921.25 feet) altitude
Up to 12,000 meters (39,370 feet)
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
