Tektronix MSO70000 Series Technical Reference page 22

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
Characteristic
< 4 GHz models,
50 Ω coupling
< 4 GHz models,
1 MΩ coupling
Offset accuracy
≥ 4 GHz models
< 4 GHz models
1–6
Description
SCALE range
1 mV/div to 50 mV/div
50.5 mV/div to 99.5 mV/div
100 mV/div to 500 mV/div
505 mV/div to 1 V/div
SCALE range
1 mV/div to 50 mV/div
50.5 mV/div to 99.5 mV/div
100 mV/div to 500 mV/div
505 mV/div to 995 mV/div
1.0 V/div to 5 V/div
5.05 V/div to 10 V/div
Net offset = offset - ( position × volts/division).
SCALE range
10 mV/div to 99.5 mV/div
100 mV/div to 0.5 V/div
SCALE range
1 mV/div to 9.95 mV/div
10 mV/div to 99.5 mV/div
100 mV/div to 1 V/div
1.01 V/div to 10 V/div
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Offset range
±1.0 V
±1.5 V - 10 divisions
±10 V
±15 V - 10 divisions
Offset range
±1 V
±1.5 V - 10 divisions
±10 V
±15 V - 10 divisions
±100 V
±150 V - 10 divisions
Offset accuracy
±(0.35% × | net offset | + 1.5 mV +
1% x Full Scale)
±(0.35% × | net offset | + 7.5 mV +
1% x Full Scale)
Offset accuracy
±(0.2% × | net offset | + 1.5 mV +
0.1 div × V/div setting)
±(0.35% × | net offset | + 1.5 mV +
0.1 div × V/div setting)
±(0.35% × | net offset | + 15 mV +
0.1 div × V/div setting)
±(0.25% × | net offset | + 150 mV +
0.1 div × V/div setting)
