Tektronix MSO70000 Series Technical Reference page 41

Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
MSO70804, 8 GHz
MSO70604,
MSO70404,
DSA70804B,
DSA70604B,
DSA70404B,
DPO70804B,
DPO70604B,
DPO70404B,
where
applicable
Gain setting
10 mV 0.54 mV
15 mV 0.73 mV
20 mV 0.86 mV
30 mV 1.34 mV
40 mV 1.67 mV
50 mV 1.94 mV
60 mV 2.41 mV
70 mV 2.87 mV
80 mV 3.34 mV
90 mV 3.70 mV
100 mV 4.28 mV
200 mV 8.36 mV
250 mV 10.23 mV
300 mV 12.10 mV
400 mV 16.61 mV
450 mV 18.57 mV
500 mV 20.53 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
7 GHz 6 GHz 5 GHz
0.51 mV 0.48 mV 0.45 mV
0.69 mV 0.64 mV 0.60 mV
0.80 mV 0.77 mV 0.72 mV
1.25 mV 1.16 mV 1.07 mV
1.58 mV 1.50 mV 1.41 mV
1.85 mV 1.76 mV 1.67 mV
2.29 mV 2.17 mV 2.04 mV
2.73 mV 2.58 mV 2.41 mV
3.17 mV 2.99 mV 2.77 mV
3.56 mV 3.34 mV 3.12 mV
3.99 mV 3.83 mV 3.46 mV
8.09 mV 7.48 mV 6.95 mV
9.86 mV 9.20 mV 8.61 mV
11.62 mV 10.92 mV 10.27 mV 9.75 mV
15.90 mV 14.99 mV 14.18 mV 12.97 mV
17.75 mV 16.78 mV 15.91 mV 14.55 mV
19.60 mV 18.58 mV 17.65 mV 16.13 mV
4 GHz 3 GHz 2 GHz
0.42 mV 0.40 mV 0.37 mV
0.55 mV 0.50 mV 0.46 mV
0.68 mV 0.60 mV 0.55 mV
0.98 mV 0.89 mV 0.78 mV
1.32 mV 1.14 mV 1.01 mV
1.58 mV 1.41 mV 1.23 mV
1.91 mV 1.70 mV 1.50 mV
2.23 mV 1.99 mV 1.76 mV
2.55 mV 2.29 mV 2.02 mV
2.90 mV 2.55 mV 2.24 mV
3.38 mV 3.00 mV 2.59 mV
6.60 mV 5.80 mV 5.08 mV
8.18 mV 7.21 mV 6.32 mV
8.62 mV 7.55 mV
11.50 mV 10.07 mV 8.28 mV
12.92 mV 11.31 mV
14.34 mV 12.55 mV 10.31 mV
1 GHz 500 MHz
0.32 mV 0.24 mV
0.39 mV 0.32 mV
0.46 mV 0.40 mV
0.67 mV 0.57 mV
0.88 mV 0.76 mV
1.01 mV 0.92 mV
1.23 mV 1.10 mV
1.44 mV 1.28 mV
1.65 mV 1.45 mV
1.89 mV 1.67 mV
2.03 mV 1.65 mV
4.19 mV 3.66 mV
5.20 mV 4.61 mV
6.21 mV 5.56 mV
7.50 mV
9.29 mV 8.46 mV
9.41 mV
1–25
