Tektronix MSO70000 Series Technical Reference page 58

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Edge trigger sensitivity, not DC
coupled, typical
≥ 4 GHz models
< 4 GHz models
Trigger level or threshold range
≥ 4 GHz models
< 4 GHz models
Trigger level or threshold accuracy,
typical
≥ 4 GHz models
< 4 GHz models
1–42
All sources, positive or negative edge, for vertical scale settings ≥10 mV/div and ≤1 V/div
Trigger Coupling
NOISE REJ
AC
HF REJ
LF REJ
Trigger coupling
NOISE REJ
AC
HF REJ
LF REJ
Trigger Source
Any channel
Auxiliary input
Line
Trigger Source
Any channel
Auxiliary input
Line
Edge trigger, DC coupled
Trigger Source
Channel 1, 2, 3, or 4
Auxiliary
Trigger Source
Channel 1, 2, 3, or 4
Auxiliary
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Sensitivity
15%FS from DC to 50 MHz
35%FS at 3 GHz
50%FS at 5 GHz
Same as DC-coupled limits for frequencies
> 100 Hz, attenuates signals <100 Hz
Same as DC-coupled limits for frequencies
< 20 kHz, attenuates signals > 20 kHz
Same as DC-coupled limits for frequencies
> 200 kHz, attenuates signals < 200 kHz
Sensitivity
3 the DC-coupled limits
Same as DC-coupled limits for frequencies
> 100 Hz, attenuates signals <100 Hz
Same as DC-coupled limits for frequencies
< 20 kHz, attenuates signals > 20 kHz
Same as DC-coupled limits for frequencies
> 200 kHz, attenuates signals < 200 kHz
Range
+120% FS from center of screen
±5.0 V
0 V, Not settable
Sensitivity
±12 divisions from center of screen
±5 V
Not settable
Accuracy
± [(2% | trigger level - net offset | ) + (3.5% FS)
+ offset accuracy]
Not specified
Accuracy
± [(2% | deflection | ) + (0.7 divisions ×
volts/division) + offset accuracy]
Not specified
