Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
Characteristic
DC voltage measurement
accuracy, < 4 GHz models
Average acquisition mode
( ≥16 averages)
Delta voltage measurement
between any two averages
of ≥16 waveforms acquired
with the same setup and
ambient conditions
Sample acquisition mode,
typical
Delta voltage measurement
between any two samples
acquired with the same setup
and ambient conditions,
typical
Position range
1–4
Description
DC accuracy (in volts)
±(DC Gain Accuracy × | reading -(offset - position) | + offset accuracy + 0.1 division)
±(DC Gain Accuracy × | reading | + 0.05 division)
±(DC Gain Accuracy × | reading -(offset - position) | + offset accuracy + 0.15 division + 0.6 mV)
±(DC Gain Accuracy × | reading | + 0.15 division + 1.2 mV)
Convert offset, position and the constant offset term to volts by multiplying by the appropriate
volts/div.
Specification applies to any sample and to the High, Low, Max, Min, Mean, Cycle Mean, RMS,
and Cycle RMS measurements. Delta volts specification applies to subtractive calculations
involving two of these measurements. Delta volts specification applies to the Positive
Overshoot, Negative Overshoot, peak-peak, and amplitude measurements.
± 5 divisions
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
