Tektronix MSO70000 Series Technical Reference page 148

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-5: Gain accuracy (cont.)
Position
Scale setting
Channel setting (Divs)
10 mV 0
Ch3
-5
5
20 mV 0
-5
5
50 mV 0
-5
5
100 mV 0
-5
5
200 mV 0
-5
5
3–52
Offset Generator
setting setting
0 V +38.0 mV
-38.0 mV
+0.45 V +538 mV
+462 mV
-0.45 V -462 mV
-538 mV
0 V +76.0 mV
-76.0 mV
+0.4 V +576.0 mV
+424.0 mV
-0.4 V -424.0 mV
-576.0 mV
0 V +190 mV
-190 mV
+0.25 V +690 mV
+310 mV
-0.25 V -310 mV
-690 mV
0 V +380 mV
-380 mV
+2.0 V +2.88 V
+2.12 V
-2.0 V -2.12 V
-2.88 V
0 V +760 mV
-760 mV
+1.25 V +3.01 V
+1.49 V
-1.25 V -1.49 V
-3.01 V
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Difference of
Measurement measurement
mean means Accuracy limits
+74.48 mV to +77.52 mV
+74.48 mV to +77.52 mV
+74.48 mV to +77.52 mV
+148.960 mV to +155.040 mV
+148.960 mV to +155.040 mV
+148.960 mV to +155.040 mV
+372.40 mV to +387.60 mV
+372.40 mV to +387.60 mV
+372.40 mV to +387.60 mV
+744.80 mV to +775.20 mV
+744.80 mV to +775.20 mV
+744.80 mV to +775.20 mV
+1.49 V to +1.55 V
+1.49 V to +1.55 V
+1.49 V to +1.55 V
