Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-11: Delta time measurement settings (cont.)
Instrument Volts/div
BWE on
MSO72004C and 50 mV
DPO72004C, 20 GHz
100 mV
MSO72004C and 10 mV
DPO72004C, 18 GHz
50 mV
100 mV
MSO71604C and 10 mV
DPO71604C, 16 GHz
50 mV
100 mV
MSO71254C and 10 mV
DPO71254C, 12.5 GHz
50 mV
100 mV
MSO70804 and 10 mV
DPO70804B, 8 GHz
50 mV
100 mV
MSO70604 and 10 mV
DPO70604B, 6 GHz
50 mV
100 mV
MSO70404 and 10 mV
DPO70404B, 4 GHz
50 mV
100 mV
3–82
Sine wave
generator Record
frequency length
11.2 GHz 10000
11.2 GHz 10000
11.2 GHz 10000
11.2 GHz 10000
10000
11.2 GHz
9.94 GHz 10000
9.94 GHz 10000
9.94 GHz 10000
7.45 GHz 10000
7.45 GHz 10000
7.45 GHz 10000
4.97 GHz 10000
4.97 GHz 10000
4.97 GHz 10000
3.73 GHz 10000
10000
3.73 GHz
3.73 GHz 10000
2.48 GHz 10000
2.48 GHz 10000
2.48 GHz 10000
Adjust the generator output as necessary to obtain 8 divisions of
displayed waveform.
d. Set up for statistics measurements:
From the button bar, touch Measure and select the More tab to show
the More Measurements menu.
Touch the Burst Width button.
Touch Setups Gating and then touch Cursor.
Touch Setup.
Touch Setups Statistics and then touch All. Set the Weight n= to 1000.
Touch Reset to reset the statistics.
Touch Setup.
Touch Setups Ref Levs and then touch Absolute.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Sample Burst Delta time rms
rate width accuracy limit
500 GS/s 10 ns 1.260 ps
500 GS/s 10 ns 1.432 ps
500 GS/s 10 ns 1.336 ps
500 GS/s 10 ns 1.182 ps
10 ns 1.234 ps
500 GS/s
500 GS/s 10 ns 1.219 ps
500 GS/s 10 ns 1.154 ps
500 GS/s 10 ns 1.159 ps
500 GS/s 10 ns 1.333 ps
500 GS/s 10 ns 1.212 ps
500 GS/s 10 ns 1.228 ps
500 GS/s 10 ns 1.354 ps
500 GS/s 10 ns 1.235 ps
500 GS/s 10 ns 1.241 ps
500 GS/s 10 ns 1.445 ps
10 ns 1.295 ps
500 GS/s
500 GS/s 10 ns 1.329 ps
500 GS/s 10 ns 1.674 ps
500 GS/s 10 ns 1.437 ps
500 GS/s 10 ns 1.478 ps
Delta time
pk-pk
accuracy limit
12.60 ps
14.32 ps
13.36 ps
11.82 ps
12.34 ps
12.19 ps
11.54 ps
11.59 ps
13.33 ps
12.12 ps
12.28 ps
13.54 ps
12.35 ps
12.41 ps
14.45 ps
12.95 ps
13.29 ps
16.74 ps
14.37 ps
14.78 ps
