Specifications (MSO/DPO5000 Series)
Table 2-1: Analog channel input and vertical specification (cont.)
Characteristic Description
Sample Measurement type
acquisition
Any sample
mode,
typical
Delta volts between any two samples
acquired with the same oscilloscope
setup and ambient conditions
Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate
volts/div term.
Analog 20 MHz, 250 MHz, and Full
bandwidth
selections
Full bandwidth, with amplitude tolerance of -3 dB and operating temperatures of ≤30 °C (86 °F).
Analog
Reduce the bandwidth by 1% for each °C above 30 °C.
bandwidth, 50 Ω,
DC coupled
Instrument
MSO5204,
DPO5204
MSO5104,
DPO5104
MSO5054,
DPO5054
MSO5034,
DPO5034
2–4
SCALE range
10 mV/div — 1 V/div
5 mV/div — 9.98 mV/div
2 mV/div — 4.98 mV/div
1 mV/div — 1.99 mV/div
5 mV/div — 1 V/div
2 mV/div — 4.98 mV/div
1 mV/div — 1.99 mV/div
5 mV/div — 1 V/div
2 mV/div — 4.98 mV/div
1 mV/div — 1.99 mV/div
2 mV/div — 1 V/div
1 mV/div — 1.99 mV/div
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
DC Accuracy (in volts)
±[DC gain accuracy × | reading - (offset - position) | + offset
accuracy +0.15 div + 0.6 mV]
Refer to DC Gain Accuracy for temperature derating information.
±[DC gain accuracy × | reading | + 0.15 div + 1.2 mV]
Refer to DC Gain Accuracy for temperature derating information.
Bandwidth
DC to 2.00 GHz
DC to 1.50 GHz
DC to 350 MHz
DC to 175 MHz
DC to 1.00 GHz
DC to 350 MHz
DC to 175 MHz
DC to 500 MHz
DC to 350 MHz
DC to 175 MHz
DC to 350 MHz
DC to 175 MHz
