Table 2-3: Trigger specifications
Characteristic
Aux In (External) trigger input
impedance, typical
Aux In (External) trigger maximum
input voltage
Aux In (External) trigger bandwidth,
typical
Trigger bandwidth, Edge, typical
Trigger bandwidth, Pulse and Logic,
typical
Edge-type trigger sensitivity, DC
coupled, typical
Trigger jitter
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Description
1 M Ω ±1% in parallel with 13 pF ±2 pF
The maximum input voltage at the BNC 300 V
Installation Category II
Derate at 20 dB/decade above 3 MHz to 30 V
250 MHz ±20%
MSO5204, DPO5204
MSO5104, DPO5104
MSO5054, DPO5054
MSO5034, DPO5034
MSO5204, DPO5204
MSO5104, DPO5104
MSO5054, DPO5054
MSO5034, DPO5034
Models
MSO5204, DPO5204
MSO5104, DPO5104
MSO5054, DPO5054
MSO5034, DPO5034
All models
All models
All models
≤10 ps for edge-type trigger
RMS
≤100 ps for non edge-type trigger modes
RMS
Specifications (MSO/DPO5000 Series)
RMS
at 30 MHz, 10 dB/decade above 30 MHz.
RMS
2 GHz
1 GHz
500 MHz
350 MHz
1 GHz
1 GHz
500 MHz
350 MHz
Trigger Sensitivity
Source
Any input 50 Ω path:
channel
0.40 div from DC to 50 MHz, increasing to
1 div at oscilloscope bandwidth
Any input 50 Ω path:
channel
1 mV/div to 4.98 mV/div – 0.75 div from
DC to 50 MHz, increasing to 1.3 div at
oscilloscope bandwidth.
≥ 5 mV/div 0.040 div from DC to 50 MHz,
increasing to 1 div at oscilloscope
bandwidth.
Any input 1 MΩ path:
channel
1 mV/div to 4.98 mV/div – 0.75 div from
DC to 50 MHz, increasing to 1.3 div at
oscilloscope bandwidth.
≥ 5 mV/div 0.040 div from DC to 50 MHz,
increasing to 1 div at oscilloscope
bandwidth.
Aux in 200 mV from DC to 50 MHz, increasing to
(External)
500 mV at 250 MHz
Line Fixed
2–11
